2U4FH-12L
28 29
English
10. Power Cable, ATX 24Pin (520mm) (Quantity: 1)
Server Board PDB
11. PMBus Cable (500mm) (Quantity: 1)
Server Board PDB
12. Power Cable, ATX 12Pin to 4*4Pin (Quantity: 1)
PDB
BPB
Connections and cable routing may dier depending on various server boards. Please refer
to the Quick Installation Guide to know the exact headers or connectors to be connected on
the server board you purchase. For more detailed information about server board compo-
nents, refer to the manual that comes with your server board.
