Daikin MC401VE [15/53] Names and functions of the operating section

Operating Manual SiE74-202

8 Operation Manual

1.6 Names and Functions of The Operating Section

When used in conjunction with a humidifier, keep

mist from being directly drawn into the unit.

Mists can lead to electric shock and/or equipment damage.

Do not use in the place of kitchen fans or cooker

hood fans.

Adverse conditions of use can shorten service-life of the

prefilter and ion filter, as well as lead to equipment damage.

Prevent combustibles (hair sprays, etc.), sparks

and incense from being drawn into the unit.

Such substances can cause fire.

If not using the unit for long periods of time,

unplug the power cable.

Dielectric breakdown can lead to leakage current and

subsequently electric shock and/or fire.

∗ Keep this manual in a handy place so that anyone operating the

equipment can refer to it quickly and easily. Ensure that anyone

unfamiliar with the equipment reads this manual before handling the

equipment.

A Front panel

B Ion filter (roll) case

Positively (+) charges minute dust particles not trapped by the

prefilter.

C Ion filter roll

Working on the principle of electrostatic attraction, the negatively (−)

charged filter catches and removes the positively (+) charged dust.

D Air outlet

E Handle (on rear)

F Inverter lamp

Activates the photocatalyst by illuminating it with light.

G Photocatalyst

Removes odors, bacteria and viruses when activated by the

inverter lamp.

∗ Do not subject the photocatalyst to excessive force. The inverter

lamp located behind it will break.

H Indicator lamps

Display operating status. See page 9.

J Prefilter

Removes comparatively large dust particles.
