SiE74-202 Safety Cautions
v
1.2 Using Icons
Icons are used to attract the attention of the reader to specific information. The meaning of each
icon is described in the table below:
Do not place water containers
such as fish bowls and flower
vases near the equipment.
Water can cause electrical shock
and equipment malfunction when it
enters the equipment.
Do not wipe with benzene or
thinner, or spray with insecticide.
Such
substances can
cause cracking,
electric shock
and/or fire.
If not using the unit for long
periods of time, unplug the power
cable.
Dielectric breakdown can lead to
leakage current and subsequently
electric shock and/or fire.
Hold the plug to unplug the power
cord from the AC outlet. Do not
pull the cord to unplug.
Otherwise electrical
shock can result or
sparks may be
generated due to
shorting.
Do not operate the equipment
without the prefilter or roll filter.
Operating the equipment without the
filter can result in equipment
malfunction.
Do not sit or stand on the
equipment.
Otherwise equipment malfunction
can result.
Do not position the equipment on
its side or tilt it during use.
Otherwise
equipment
malfunction can
result.
Ventilate the room frequently
when used together with a
heating device.
This product does not remove
carbon monoxide. Insufficient
ventilation can result in carbon
monoxide poisoning.
Caution
