Removal Procedure of MC401VE SiE74-202
34 Removal Procedure
1.4 Removal of PCB
Procedure Warning Be sure to turn off all power supplies before disassembling work
Step Procedure Points
1 Unscrew two screws at
the both side of the main
body.
Disengage 6 hooks.
2Disengage the 6 hooks to
remove display PCB.
