Daikin MC401VE [44/53] Removal of safety switch
![Daikin MC401VE [44/53] Removal of safety switch](/views2/1694152/page44/bg2c.png)
SiE74-202 Removal Procedure of MC401VE
Removal Procedure 37
1.6 Removal of Safety Switch
Procedure Warning Be sure to turn off all power supplies before disassembling work
Step Procedure Points
1 To remove safety switch,
push it out from back
side.
