4 5
English
Support OS
OS Microso® Windows®
- Windows Server 2008 R2 (64 bit)
- Windows Server 2012 (64 bit)
- Windows Server 2012 R2 (64 bit)
- Windows Server 2016 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.8 (32 / 64 bit) / 7.2 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (32 / 64 bit) / 12.0 SP1
(64 bit)
- Ubuntu 16.04 (64 bit) / 15.10 (64 bit) (AHCI mode)
- Vmware ESXi 6.0
* Please refer to our website for the latest OS support list.
* Before installing the Linux OS, please rst enter the BIOS settings, go to
“Advanced” > “Chipset Conguration” and set “IGPU Multi-Monitor” option
to “Disabled”.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
NOTE: Please refer to our website for the latest specications.
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
