E3C236D4I-44E85
2 3
English
UID 1
Dedicate LAN 1 x RJ45 Dedicated IPMI LAN port
Internal Connector
Auxiliary Panel
Header
1 (include chassis intrusion, FSMB, 2Front LANLED,
LOCBLED)
Speaker Header 1
TR1 Header 1
TPM Header 1
Fan Header 3 x (4 pins)
ATX Power 1x (24-pin)
SATA Power
Header
1x 4-pin (DC output for 5V HDD)
Type A USB 3.0
Port
1
USB 3.0 Header 1 (supports 2 USB3.0 ports)
ME/SPS Recovery 1
ClearCMOS 1 (header and short pin)
NMI button 1
SGPIO 2
COM Header 1
SATA DOM 1
NMI button 1
Front Panel 4(1rst, 1pwrbtn, 1hddled, 1pwrled)
BMC_SMBUS 1
M.2 1 (2242)
IPMB Header 1
System BIOS
BIOS Ty pe 128Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/PCH/LAN Temperature Sensing
- MB/Card Side/TR1 Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: ATX+5VSB, +3VSB, CPU_VCORE,
+VCCSA, VCCM, +V1.0M, +VCCIO, VCCST_SFR, VPPM,
+3V, +5V, +12V, +BAT
