English

Serial Port for Out-of-Band Management/Windows Emergency

Management Services (EMS)

Out-of-Band Mgmt Port

Microso Windows Emergency Management Services (EMS) allows for remote

management of a Windows Server OS through a serial port.

Terminal Type

Use this item to select the preferred terminal emulation type for out-of-band management.

It is recommended to select [VT-UTF8].

Option Description

VT100 ASCII character set

VT100+ Extended VT100 that supports color and function keys

VT-U TF8 UTF8 encoding is used to map Unicode chars onto 1 or more bytes

ANSI Extended ASCII character set

Bits Per Second

Use this item to select the serial port transmission speed. The speed used in the host

computer and the client computer must be the same. Long or noisy lines may require lower

transmission speed. e options include [9600], [19200], [57600] and [115200].

Flow Control

Use this item to set the flow control to prevent data loss from buffer overf low. When

sending data, if the receiving buers are full, a "stop" signal can be sent to stop the data

ow. Once the buers are empty, a "start" signal can be sent to restart the ow. Hardware

ow uses two wires to send start/stop signals. e options include [None], [Hardware RTS/

CTS], and [Soware Xon/Xo].

Data Bits

Parity

Stop Bits
