2 3
English
1.2 Specications
EP2C612D8HM
MB Physical Status
Form Factor Half Width
Dimension 18.6’’ x 6.5’’ (47.2 cm x 16.5 cm)
Processor System
CPU Intel® Xeon® processor E5-2600 v3/v4* series
*BIOS version 2.0 or above is required.
Socket Dual Socket LGA 2011 R3
*
Please use a narrow type CPU Cooler
Chipset Intel® C612
System Memory
Capacity 8 DIMM slots
Type - Quad Channel memory technology
- Support DDR4 2400*/2133/1866/1600 RDIMM and
LRDIMM
*Only E5-2600 V4 CPUs support DDR4 2400.
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
PCIe 3.0 x 16 2 slots
PCIe 3.0 x 8 2 slots
Storage
SATA Controller Intel®C612 : 10 x SATA3 (8 from 2x mini SAS HD connector),
support RAID 0, 1, 5, 10
Ethernet
Interface N/A
LAN 1 x RJ45 Dedicated IPMI LAN port
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
LAN Port 1 (IPMI) Lan port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
