Specifications Si38-606
8 Specifications
1. Specifications
1.1 Outdoor Units
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name RXM8MY1 RXM10MY1
★
1 Cooling Capacity (19.5°CWB)
kcal / h 19,400 24,300
Btu / h 76,800 96,200
kW 22.5 28.2
★
2 Cooling Capacity (19.0°CWB) kW 22.4 28.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1600×930×765 1600×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 19.36+14.68 19.36+14.68
Number of Revolutions r.p.m 6480, 2900 6480, 2900
Motor Output×Number
of Units
kW (1.1+4.5)×1 (2.1+4.5)×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.75×1
Air Flow Rate m³/min 175 210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
12.7 (Brazing Connection)
φ
12.7 (Brazing Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
φ
28.6 (Brazing Connection)
Oil Equalizer Tube mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
Machine Weight (Mass) kg 235 290
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
Capacity Control % 14~100 14~100
Refrigerant
Refrigerant Name R-22 R-22
Charge kg 13.1 14.9
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
SUNISO 4GSDID-K SUNISO 4GSDID-K
Charge Volume L 1.9+1.6 1.9+1.6
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C : 4D052966 C : 4D052967
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
