Si38-606 Specifications
Specifications 9
1.2 Indoor Units
Ceiling Mounted Cassette Type (Double-flow)
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level
difference; 0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 Operation sound is measured in an anechoic chamber.
Model FXC20LVE FXC25LVE FXC32LVE FXC40LVE
★
1 Cooling Capacity (19.5°CWB)
kcal/h 2,000 2,500 3,200 4,000
Btu/h 7,800 9,900 12,600 16,000
kW 2.3 2.9 3.7 4.7
★
2 Cooling Capacity (19.0°CWB) kW 2.2 2.8 3.6 4.5
★
3 Heating Capacity
kcal/h 2,200 2,800 3,400 4,300
Btu/h 8,500 10,900 13,600 17,000
kW 2.5 3.2 4.0 5.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 305×775×600 305×775×600 305×775×600 305×990×600
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.5 2×10×1.5 2×10×1.5 2×10×1.5
Face Area m² 2×0.100 2×0.100 2×0.100 2×0.145
Fan
Model D17K2AA1 D17K2AB1 D17K2AB1 2D17K1AA1
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 10×1 15×1 15×1 20×1
Air Flow Rate (H/L)
m³/min 7/5 9/6.5 9/6.5 12/9
cfm 247/177 318/230 318/230 424/318
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Wool/Urethane Foam Glass Wool/Urethane Foam Glass Wool/Urethane Foam Glass Wool/Urethane Foam
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight (Mass) kg 26 26 26 31
★
5 Sound Level (H/L) (220V) dBA 32/27 34/28 34/28 34/29
Safety Devices
Fuse, Thermal Protector for
Fan Motor
Fuse, Thermal Protector for
Fan Motor
Fuse, Thermal Protector for
Fan Motor
Fuse, Thermal Protector for
Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-22 ; M Series R-22 ; M Series R-22 ; M Series R-22 ; M Series
Decoration
Panels
(Option)
Model BYBC32G-W1 BYBC32G-W1 BYBC32G-W1 BYBC50G-W1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 53×1,030×680 53×1,030×680 53×1,030×680 53×1,245×680
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 8 8 8 8.5
Standard Accessories
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Drawing No. 3D034244A
()()()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
