Daikin FXM125LVE [32/254] Ceiling mounted built in type
![Daikin FXM125LVE [32/254] Ceiling mounted built in type](/views2/1697150/page32/bg20.png)
Si38-606 Specifications
Specifications 21
Ceiling Mounted Built-in Type
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level
difference; 0m. (Heat pump only)
★
4 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means “High static pressure-Standard -Low static pressure”.
★
5 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means “High static pressure-Standard”.
6 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
★
7 Operation sound is measured in an anechoic chamber.
Model FXS20LVE FXS25LVE FXS32LVE
★
1 Cooling Capacity (19.5°CWB)
kcal/h 2,000 2,500 3,200
Btu/h 7,800 9,900 12,600
kW 2.3 2.9 3.7
★
2 Cooling Capacity (19.0°CWB) kW 2.2 2.8 3.6
★
3 Heating Capacity
kcal/h 2,200 2,800 3,400
Btu/h 8,500 10,900 13,600
kW 2.5 3.2 4.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 300×550×800 300×550×800 300×550×800
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.75 3×14×1.75 3×14×1.75
Face Area m² 0.088 0.088 0.088
Fan
Model D18H3A D18H3A D18H3A
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number of
Units
W 50×1 50×1 50×1
Air Flow Rate
(H/L)
(50Hz) m³/min 9/6.5 9/6.5 9.5/7
(60Hz) m³/min 9/6.5 9/6.5 9.5/6.5
★
4 Static
external pressure
(50Hz) Pa 88-39-20 88-39-20 64-39-15
(60Hz) Pa 73-24-10 73-24-10 86-42-10
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
φ
6.4 (Flare Connection)
Gas Pipes mm
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
φ
12.7 (Flare Connection)
Drain Pipe mm
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
Machine Weight (Mass) kg 30 30 30
★
6 Sound Level (H/L) (220V) dBA 37/32 37/32 38/32
Safety Devices
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-22 : M Series R-22 : M Series R-22 : M Series
Decoration
Panel
(Option)
Model
BYBS32DJW1 BYBS32DJW1 BYBS32DJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 55×650×500 55×650×500 55×650×500
Weight kg 3 3 3
Standard Accessories
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Operation Manual, Installation
Manual, Paper Pattern for Installation,
Drain Hose, Clamp Metal, Insulation
for Fitting, Sealing Pads, Clamps,
Screws, Washers.
Drawing No. 3D036931
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
