Specifications Si38-606
12 Specifications
Ceiling Mounted Cassette Type (Multi-flow)
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level
difference; 0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 Operation sound is measured in an anechoic chamber.
Model FXF63LVE FXF80LVE FXF100LVE FXF125LVE
★
1 Cooling Capacity (19.5°CWB)
kcal/h 6,300 8,000 10,000 12,500
Btu/h 24,900 31,700 39,600 49,500
kW 7.3 9.3 11.6 14.5
★
2 Cooling Capacity (19.0°CWB) kW 7.1 9.0 11.2 14.0
★
3 Heating Capacity
kcal/h 6,900 8,600 10,800 13,800
Btu/h 27,300 34,100 42,700 54,600
kW 8.0 10.0 12.5 16.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 246×840×840 246×840×840 288×840×840 288×840×840
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.2 2×10×1.2 2×12×1.2 2×12×1.2
Face Area m² 0.454 0.454 0.544 0.544
Fan
Model QTS46D14M QTS46D14M QTS46C17M QTS46C17M
Type Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 30×1 30×1 120×1 120×1
Air Flow Rate (H/L)
m³/min 18.5/14 20/15 26/21 30/24
cfm 653/494 706/530 918/741 1,059/847
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form Polyurethane Form
Piping
Connections
Liquid Pipes mm
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
φ
19.1 (Flare Connection)
φ
19.1 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight (Mass) kg 25 25 29 29
★
5 Sound Level (H/L)(cooling) dBA 33/28 36/31 39/33 42/36
Safety Devices FuseFuseFuseFuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-22 ; M Series R-22 ; M Series R-22 ; M Series R-22 ; M Series
Decoration
Panels
(Option)
Model BYCP125D-W1 BYCP125D-W1 BYCP125D-W1 BYCP125D-W1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 45×950×950 45×950×950 45×950×950 45×950×950
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 5.5 5.5 5.5 5.5
Standard Accessories
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Drawing No. 3D034210A
()()()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
