Troubleshooting by Remote Controller Si38-606
114 Troubleshooting
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
Indoor
Unit
A0 999Error of external protection device 118
A1 999PC board defect, E
2
PROM defect 119
A3 999Malfunction of drain level control system (S1L, 33H) 120
A6 999Fan motor (MF) lock, overload 122
A7 879Malfunction of swing flap motor (MA) 123
A9 999Malfunction of moving part of electronic expansion
valve (20E)
125
AF 879Drain level about limit 127
AH 879Malfunction of air filter maintenance —
AJ 999Malfunction of capacity setting 128
C4 999Malfunction of thermistor (R2T) for heat exchange
(loose connection, disconnection, short circuit,
failure)
129
C5 999Malfunction of thermistor (R3T) for gas pipes (loose
connection, disconnection, short circuit, failure)
130
C9 999Malfunction of thermistor (R1T) for air inlet (loose
connection, disconnection, short circuit, failure)
131
CJ 888Malfunction of thermostat sensor in remote controller 132
Outdoor
Unit
E1 999PC board defect 133
E3 999Actuation of high pressure switch 134
E4 999Actuation of low pressure sensor 135
E5 999Compressor motor lock 136
E6 999Standard compressor lock or over current 137
E7 999Malfunction of outdoor unit fan motor 138
E9 999Malfunction of moving part of electronic expansion
valve (Y1E~3E)
140
F3 999Abnormal discharge pipe temperature 142
F6 999Refrigerant overcharged 143
H3 879Malfunction of High pressure switch —
H4 999Actuation of Low pressure switch —
H7 999Abnormal outdoor fan motor signal 144
H9 999Malfunction of thermistor (R1T) for outdoor air (loose
connection, disconnection, short circuit, failure)
145
J2 999Current sensor malfunction 146
J3 999Malfunction of discharge pipe thermistor (R31~33T)
(loose connection, disconnection, short circuit,
failure)
147
J5 999Malfunction of thermistor (R2T) for suction pipe
(loose connection, disconnection, short circuit,
failure)
148
J6 999Malfunction of thermistor (R4T) for heat exchanger
(loose connection, disconnection, short circuit,
failure)
149
J7 999Malfunction of header thermistor —
J8 999Malfunction of thermistor (R7T) for oil equalizing pipe.
(loose connection, disconnection, short circuit,
failure)
—
J9 999Malfunction of receiver gas pipe thermistor (R5T) 150
JA 999Malfunction of discharge pipe pressure sensor 151
JC 999Malfunction of suction pipe pressure sensor 152
L0 999Inverter system error —
L4 999Malfunction of inverter radiating fin temperature rise 153
L5 999Inverter compressor motor grounding, short circuit 154
L6 999Compressor motor coil grounding on short circuit —
L8 999Inverter current abnormal 155
L9 999Inverter start up error 156
