List of Electrical and Functional Parts Si38-606
226 Appendix
Parts Name Symbol
Model
Remark
FXL
20LVE
FXL
25LVE
FXL
32LVE
FXL
40LVE
FXL
50LVE
FXL
63LVE
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
C/O BRC4C64
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
15W 1
φ
25W 1
φ
35W
Thermal protector 135°C : OFF 120°C : ON
Capacitor for Fan Motor
C1R 1.0
µ
F-400V 0.5
µ
F-400V 1.0
µ
F-400V 1.5
µ
F-400V 2.0
µ
F-400V
Thermistors
Thermistor (Suction Air) R1T
ST8601-6
φ
4 L1250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-9
φ
8 L2500
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602A-9
φ
6 L2500
20k
Ω
(25°C)
Others
Fuse F1U AC250V 10A
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXN
20LVE
FXN
25LVE
FXN
32LVE
FXN
40LVE
FXN
50LVE
FXN
63LVE
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
C/O BRC4C64
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
15W 1
φ
25W 1
φ
35W
Thermal protector 135°C : OFF 120°C : ON
Capacitor for Fan Motor C1R 1.0
µ
F-400V 0.5
µ
F-400V 1.0
µ
F-400V 1.5
µ
F-400V 2.0
µ
F-400V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-6
φ
4 L1250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-9
φ
8 L2500
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602A-9
φ
6 L2500
20k
Ω
(25°C)
Others
Fuse F1U AC250V 10A
Transformer T1R TR22H21R8
