Special Control Si38-606
52 Function
3.4 Restart Standby
Actuator Operation
Compressor OFF
Outdoor unit fan
Ta>30°C: STEP5
Ta≤30°C: OFF
Main motorized valve (EV1) 0 pls
Subcooling motorized valve (EV2) 0 pls
Hot gas bypass valve (SVP) OFF
Oil equalization valve (SVO) ON
Receiver gas charging valve (SVL) OFF
Receiver gas discharging valve (SVG) OFF
Non-operating unit gas discharging valve (SVSG) OFF
Non-operating unit liquid pipe stop valve (SVSL) ON
Ending conditions 5 min.
