Accessories ED39-865
46 FXFQ-P (R-410A)
Optional Accessories (for Controls)
Note:
1. Installation box is necessary for each adaptor marked .
2. Up to 2 adaptors can be fixed for each installation box.
3. Only one installation box can be installed for each indoor unit.
Type
Item
FXFQ-P
Remote controller
Wireless
H/P BRC7F634F
C/O BRC7F635F
Wired BRC1C62
Wired remote controller with weekly schedule timer BRC1D61
Adaptor for wiring
KRP1C63
Wiring adaptor for electrical appendices (1)
KRP2A62
Wiring adaptor for electrical appendices (2)
KRP4AA53
Remote sensor KRCS01-4B
Installation box for adaptor PCB
Note 2,3
KRP1H98
External control adaptor for outdoor unit
(Must be installed on indoor units)
DTA104A62
Central remote controller DCS302CA61
Unified ON/OFF controller DCS301BA61
Schedule timer DST301BA61
Intelligent Touch controller DCS601C51
