25 English
9. MOUNTING DECORATION PANEL
〈〈If test operation is required before mounting the decoration panel, “10. FIELD SETTING AND TEST
OPERATION” can be carried out before “9. MOUNTING DECORATION PANEL”.〉〉
CAUTION
In case of a wireless remote controller, unless the decoration panel is mounted, field setting and test operation
cannot be carried out.
Refer to the installation manual attached to the decoration panel.
• After the decoration panel is mounted, check if no clearance exists between the panel and the unit.
• If test operation is carried out before mounting the decoration panel, check the swing blade action after the
panel is mounted.
10. FIELD SETTING AND TEST OPERATION
〈〈Refer to also the installation manual attached to the outdoor unit.〉〉
CAUTION
Before carrying out field setting, check the items mentioned in the clause 2 “1. Items to be checked after the
installation work is completed” on page 4.
• Check if all the installation and piping works for the air conditioner are completed.
• Check if the control box lids of the air conditioner are closed.
< FIELD SETTING >
〈〈After turn on the power supply, carry out field setting from the remote controller according to the
installation state.〉〉
• Carry out setting at 3 places, “Mode No.”, “FIRST CODE No.” and “SECOND CODE No.”.
The settings shown by “ ” in the table indicate those when shipped from the factory.
• The method of setting procedure and operation is shown in the installation manual attached to the remote
controller.
(Note)Though setting of “Mode No.” is carried out as a group, if you intend to carry out individual setting by
each indoor unit or confirmation after setting, carry out setting with the Mode No. shown in the paren-
thesis ( ).
• In case of remote control, for changeover of input to FORCED OFF or to ON/OFF OPERATION.
[1] Enter into the field setting mode with the remote controller.
[2] Select Mode No. “12”.
[3] Set the FIRST CODE No. to “1”.
[4-1] For FORCE OFF, set the SECOND CODE No. to “01”.
[4-2] For ON/OFF OPERATION, set the SECOND CODE No. to “02”.
(It is set to FORCE OFF when shipped from the factory.)
•
Ask your customer to keep the manual attached to the remote controller together with the operation manual.
• Do not carry out settings other than those shown in the table.
10-1 SETTING CEILING HEIGHT (20-63 TYPE ONLY)
• Set the SECOND CODE No. according to the ceiling height as shown in the Table 4.
Ta ble 4
Setting Ceiling height (m) Mode No. FIRST CODE No. SECOND CODE No.
Standard 2.7 or less 13 (23)
001
501
High ceiling 1 2.7 - 3.0 13 (23)
002
503
High ceiling 2 3.0 - 3.5 13 (23)
003
503
01_EN_3P249378-7M.fm Page 25 Wednesday, September 12, 2012 1:05 PM
