English 26
10-2 SETTING WHEN AN OPTIONAL ACCESSORY IS ATTACHED
• For setting when attaching an optional accessory, refer to the installation manual attached to the optional
accessory.
10-3 WHEN USING WIRELESS REMOTE CONTROLLER
• When using a wireless remote controller, it is necessary to set the wireless remote controller address.
Refer to the installation manual attached to the wireless remote controller.
10-4 SETTING FAN SPEED DURING THERMOSTAT OFF
• Set the fan speed according to the using environment after consultation with your customer.
• When the fan speed is changed, explain the set fan speed to your customer.
Ta ble 5
10-5 SETTING FILTER SIGN
• A message to inform the air filter cleaning time will be indicated on the remote controller.
• Set the SECOND CODE No. shown in the Table 6 according to the amount of dust or pollution in the room.
• Though the indoor unit is equipped with the long life filter, it is necessary to periodically clean the filter to
avoid clogging of the filter. Please also explain the set time to the customer.
• The periodical filter cleaning time can be shortened depending on the environment.
Ta ble 6
* Use “No indication” setting when cleaning indication is not necessary such as the case of periodical clean-
ing being carried out.
Setting Mode No.
FIRST CODE
No.
SECOND
CODE No.
Fan speed during cooling
thermostat OFF
LL (Extra low)
12 (22) 6
01
Setting 02
Fan speed during heating
thermostat OFF
LL (Extra low)
12 (22) 3
01
Setting 02
Contamination Hours until indication Mode No. FIRST CODE No.
SECOND CODE
No.
Normal Approx. 2500 hrs
10 (20)
0
01
More contaminated Approx. 1250 hrs 02
With indication
3
01
No indication* 02
