SiBE34-703 Outline of Control (Indoor Unit)
Function 63
6.5 View of Operations of Swing Flaps
Swing flaps work as following.
Fan
Flap control
FXFQ
FXCQ
FXKQ
FXHQ
FXAQ
Heating
Hot-start from
defrosting
Swinging OFF Level Level Level
Setting the wind direction OFF Level Level Level
Defrosting
Swinging OFF Level Level Level
Setting the wind direction OFF Level Level Level
Thermostat is off
Swinging LL Level Level Level
Setting the wind direction LL Level Level Level
Hot-start from the
state that the
thermostat is off
Swinging LL Level Level Level
Setting the wind direction LL Level Level Level
Halt
Swinging OFF Level Level Level
Setting the wind direction OFF Level Level Level
Cooling
Thermostat of
microcomputer-dry
is on
Swinging L
*1
Swinging Swinging Swinging
Setting the wind direction L
*1
Set up Set up Set up
Thermostat of
microcomputer-dry
is off
Swinging OFF
or
L
Swinging Swinging Swinging
Setting the wind direction Set up Set up Set up
Cooling thermostat
is off
Swinging Set up Swinging Swinging Swinging
Setting the wind direction Set up Set up Set up Set up
Halt
Swinging OFF Level Level Level
Setting the wind direction OFF Set up Level Level
Microcomputer is
controlled (including
the cooling state)
Swinging L Swinging Swinging Swinging
Setting the wind direction L Set up Set up Set up
* 1. Only in FXFQ case, L or LL.
