Field Setting SiBE34-703
78 Test Operation
Air Flow Direction Setting
Set the air flow direction of indoor units as given in the table below. (Set when optional air outlet
blocking pad has been installed.) The second code No. is factory set to “01.”
Setting Table
Setting of Air Flow Direction Adjustment
Only the model FXKQ has the function.
When only the front-flow is used, sets yes/no of the swing flap operation of down-flow.
Setting Table
Mode No. First Code No.
Second Code
No.
Setting
13 (23) 1
01 F : 4-direction air flow
02 T : 3-direction air flow
03 W : 2-direction air flow
Setting Mode No. First Code No. Second Code No.
Down-flow operation: Yes
13 (23) 3
01
Down-flow operation: No 02
