SiBE34-703 Troubleshooting by Remote Controller
Troubleshooting 117
Outdoor Unit LA 999Malfunction of power unit —
LC 999Malfunction of transmission between inverter and
control PC board
162
P1 999High voltage of capacitor in main inverter circuit. 163
System
U0 879Low pressure drop due to refrigerant shortage or
electronic expansion valve failure
164
U1 999Reverse phase / open phase —
U2 999Power supply insufficient or instantaneous failure 166
U3 999Check operation is not completed. 168
U4 999Malfunction of transmission between indoor and
outdoor units
169
U5 999Malfunction of transmission between remote
controller and indoor unit
171
U5 787Failure of remote controller PC board or setting
during control by remote controller
171
U7 999Malfunction of transmission between outdoor units —
U8 997Malfunction of transmission between main and sub
remote controllers (malfunction of sub remote controller)
172
U9 999Malfunction of transmission between indoor unit and
outdoor unit in the same system
173
UA 999Improper combination of indoor and outdoor units,
indoor units and remote controller
175
UC 888Address duplication of central remote controller 176
UE 999Malfunction of transmission between central remote
controller and indoor unit
177
UF 999Refrigerant system not set, incompatible wiring /
piping
179
UH 999Malfunction of system, refrigerant system address
undefined
180
Central
Remote
Controller
and
Schedule
Timer
UE 999Malfunction of transmission between central remote
controller and indoor unit
181
M1 8 or 79 9Central remote controller PC board defect
Schedule timer PC board defect
182
M8 8 or 79 9Malfunction of transmission between optional
controllers for centralized control
183
MA 8 or 79 9Improper combination of optional controllers for
centralized control
184
MC 8 or 79 9Address duplication, improper setting 186
Heat
Reclaim
Ventilation
64 879Indoor unit’s air thermistor error —
65 879Outside air thermistor error —
68 879Malfunction of HVU —
6A 879Damper system alarm —
6A 999Damper system + thermistor error —
6F 879Malfunction of simple remote controller —
94 999Internal transmission error —
8: ON 7: OFF 9: Blink
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
The system operates for malfunction codes indicated in black squares, however, be sure to check and repair.
