Troubleshooting by Remote Controller SiBE39-402
96 Troubleshooting
1.2 Self-Diagnosis by Wired Remote Controller
Explanation If operation stops due to malfunction, the remote controller’s operation LED blinks, and
malfunction code is displayed. (Even if stop operation is carried out, malfunction contents are
displayed when the inspection mode is entered.) The malfunction code enables you to tell what
kind of malfunction caused operation to stop.
Inspection
display
Inspection/
test buttom
Displays the
malfunction code.
