Daikin FXDQ25NVE [13/218] Indoor units
![Daikin FXDQ25NVE [13/218] Indoor units](/views2/1705698/page13/bgd.png)
Capacity Range SiBE39-402
4 General Information
3. Capacity Range
Outdoor Units
Indoor Units
Capacity Range 4HP 5HP 6HP
RXYSQ 4M7 5M7 6M7
No of Indoor Units
to be Connected
689
Total Capacity
Index of Indoor
Units to be
Connected
50~130 62.5~162.5 70~182
Capacity Range
0.8
HP
1
HP
1.25
HP
1.6
HP
2
HP
2.5
HP
3.2
HP
4
HP
5
HP
Capacity Index 20 25 31.25 40 50 62.5 80 100 125
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M7 25M7 32M7 40M7 50M7 63M7 80M7 — 125M7
Ceiling Mounted
Cassette Type
(Multi Flow)
600
×
600
FXZQ 20M 25M 32M 40M 50M — — — —
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ 20M7 25M7 32M7 40M7 50M7 63M7 80M7 — 125M7
Ceiling Mounted
Cassette Corner
Type
FXKQ — 25M 32M 40M — 63M — — —
Slim Ceiling Mounted
Built-in Type
FXDQ 20N 25N 32N 40N 50N 63N — — —
Ceiling Mounted
Built-in Type
FXDQ20M725M7———————
Ceiling Mounted
Built-in Type
FXSQ 20M7 25M7 32M7 40M7 50M7 63M7 80M7 100M7 125M7
Ceiling Mounted
Duct Type
FXMQ — — — 40M 50M 63M 80M 100M 125M
Ceiling Suspended
Type
FXHQ — — 32M — — 63M — 100M —
Wall Mounted Type
FXAQ 20M 25M 32M 40M 50M 63M — — —
Floor Standing Type
FXLQ 20M 25M 32M 40M 50M 63M — — —
Concealed
Floor Standing Type
FXNQ 20M 25M 32M 40M 50M 63M — — —
