SiBE39-402 Specifications
Specifications 7
Notes: H1 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m,
level difference : 0m.
H2 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB or 6°CWB / Equivalent piping length : 7.5m,
level difference : 0m.
Model Name RXYSQ6M7V3B
H1 Cooling Capacity
kcal / h 13,300
Btu / h 52,900
kW 15.5
H2 Heating Capacity
kcal / h 15,400
Btu / h 61,400
kW 18.0
Casing Color Ivory White
Dimensions: (H×W×D) mm 1,345×900×320
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 19.36
Number of Revolutions r.p.m 6,480
Motor Output×Number
of Units
kW 3.5×1
Starting Method Direct on line
Fan
Type Propeller Fan
Motor Output W 70×2
Air Flow Rate m³/min 106
Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 (Flare Connection)
Gas Pipe mm φ19.1 (Brazing Connection)
Machine Weight kg 127
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Inverter
Overload Protector, Fusible Plugs, Fuse
Defrost Method Reverse cycle defrosting
Capacity Control % 24~100
Refrigerant
Refrigerant Name R410A
Charge kg 5.8
Control Electronic Expansion Valve
Refrigerator
Oil
DAPHNE FVC68D
Charge Volume L 1.6
Standard Accessories Installation Manual, Operation Manual, Clamps, Auxiliary Piping
Drawing No. 4D045796
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
