Specifications SiBE39-402
6 Specifications
1. Specifications
1.1 Outdoor Units
Notes: H1 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m,
level difference : 0m.
H2 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB or 6°CWB / Equivalent piping length : 7.5m,
level difference : 0m.
Model Name RXYSQ4M7V3B RXYSQ5M7V3B
H1 Cooling Capacity
kcal / h 9,600 12,000
Btu / h 38,200 47,700
kW 11.2 14.0
H2 Heating Capacity
kcal / h 10,700 13,700
Btu / h 42,600 54,600
kW 12.5 16.0
Casing Color Ivory White Ivory White
Dimensions: (H×W×D) mm 1,345×900×320 1,345×900×320
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 19.36 19.36
Number of Revolutions r.p.m 6,480 6,480
Motor Output×Number
of Units
kW 2.5×1 3.0×1
Starting Method Direct on line Direct on line
Fan
Type Propeller Fan Propeller Fan
Motor Output W 70×2 70×2
Air Flow Rate m³/min 106 106
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipe mm φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Machine Weight kg 127 127
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Inverter Overload Protector, Fusible Plugs, Fuse
High Pressure Switch, Fan Driver Overload Protector,
Inverter Overload Protector, Fusible Plugs, Fuse
Defrost Method Reverse cycle defrosting Reverse cycle defrosting
Capacity Control % 24~100 24~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 5.8 5.8
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
DAPHNE FVC68D DAPHNE FVC68D
Charge Volume L 1.6 1.6
Standard Accessories Installation Manual, Operation Manual, Clamps Installation Manual, Operation Manual, Clamps
Drawing No. 4D045796
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
