Method of Troubleshooting SiE30-408
92 Troubleshooting
3.8.3 How to Use Monitor on Inverter PC Board
The latest contents of malfunction stop can be obtained by LED display on inverter PC board.
Each malfunction stop of inverter has retry function. Within the specified frequency of retry, the
unit merely goes into 5 minutes standby mode, and malfunction cannot be determined.
When the retry frequency completes within 60 minutes, malfunction is determined and
malfunction code will be displayed on indoor remote controller.
9: BLINK
8: ON
7: OFF
LED A 1 2 3 4 Malfunction contents Number of retry times
97777
Normal —
97778
Malfunction of fin thermal 3
98877
Malfunction of sensor system 0
98778
Voltage shortage 3
97787
Instantaneous overcurrent 3
97888
Electronic thermal 3
98888
Stall prevention 3
97877
Open phase detection 3
77777
Microcomputer malfunction Infinite
