Biostar B150GT5 Версия 5.x [5/79] Rear panel connectors

Chapter 1: Introducon | 5

Z170GT5 & B150GT5

1.4 Rear Panel Connectors

Note

 HDMI,DVI-D&VGAportsonlyworkwithanIntel®integratedGraphicsProcessor.

 Maximumresoluon

HDMI:4096x2160@24Hz,compliantwithHDMI1.4a

VGA:1920x1200@60Hz

DVI-D:1920x1200@60Hz

 Themainboardsupportsthreeonboarddisplayoutputsatsamemeandthedisplayoutput

conguraoncanbeselectedinIntelgraphicsdriverulity.
