AC/DC Power Modules
TMT Series 10 to 50 Watt
Input Specifications
Input voltage – nominal 115 / 230 VAC
– range 85 – 264 VAC
85 – 370 VDC
below 110 VDC: 1.2%/V output power derating
Input frequency 47 – 63 Hz
Input current full load 115 VAC / 230 VAC
10 watt models: 210 mA / 140 mA typ
15 watt models: 280 mA / 180 mA typ.
30 watt models: 570 mA / 360 mA typ.
50 watt models: 870 mA / 540 mA typ.
Inrush current 115 VAC / 230 VAC
24 A / 36 A
External input fuse required (recommended values) 10–15 watt models: 1.0 A slow blow
30 watt models: 2.0 A slow blow
50 watt models: 3.15 A slow blow
Output Specifications
Voltage set accuracy ±2 %
Regulation – Input variation 20 mV max.
– Load variation
single output models (0–100%): 50 mV max.
dual and triple output models (min. load 10%): 500 mV max.
Ripple and noise (20MHz bandwidth) 150 mVpk-pk max.
Overload protection by current limit >105 % Inom (Ipeak of triple output models)
automatic recovery (long term short circuit
operation may cause damage to the unit)
Capacitive load 10‘000 µF max.
Rise time 200 ms typ.
Hold-up time 115 VAC / 230 VAC
15/50 watt models: 25 ms / 130 ms min.
other models: 17 ms / 93 ms min.
Page 2 of 8
Order Code Output Output 1 Output 2 Output 3
PCB-Mount Chassis Mount
with
Power
with Solder Pins
Screw Terminal Block
max.
TMT 15212 TMT 15212C
15 Watt
+12 VDC/625 mA –12 VDC/625 mA
TMT 15215 TMT 15215C
+15 VDC/500 mA –15 VDC/500 mA
TMT 30212 TMT 30212C
+12 VDC/1250 mA –12 VDC/1250
mA
TMT 30215 TMT 30215C
+15 VDC/1000 mA –15 VDC/1000
mA
TMT 30252 TMT 30252C
+5 VDC/3000
mA
1)
+12 VDC/1200
mA
4)
TMT 30522 TMT 30522C 30 Watt
+5 VDC/3000
mA
1)
+12 VDC/1000 mA
5)
–12 VDC/250 mA
7)
TMT 30515 TMT 30515C
+5 VDC/3000
mA
1)
+15 VDC/500 mA
–15 VDC/500 mA
TMT 30503
+3.3 VDC/6000
mA
2)
+5 VDC/1500 mA
5)
+12 VDC/250 mA
7)
TMT 30505
+5 VDC/5000
mA
3)
+3.3 VDC/1000 mA
6)
+12 VDC/250 mA
7)
Dual- and Triple Output Models
Peak current:
1)
4500 mA
2)
7500 mA
3)
6000 mA
4)
1800 mA
5)
2000 mA
6)
1500 mA
7)
500 mA
<30 sec. 10 % duty cycle max, total load not to exceed 30 Watt.
