TRACO POWER TMT 15112C [8/8] Ac dc power modules
![TRACO POWER TMT 15112C [8/8] Ac dc power modules](/views2/1709352/page8/bg8.png)
J
enatschstrasse 1 · CH-8002 Zurich · Switzerland
Tel. +41 43 311 45 11 · Fax +41 43 311 45 45 · info@traco.ch · www.tracopower.com
Page 8 of 8
AC/DC Power Modules
TMT Series 10 to 50 Watt
DIN-Rail Mounting Kit
Order Code For Models
TMT-MK1
TMT 15xxxC
TMT-MK2
TMT 30xxxC single & ±12/±15VDC
TMT-MK5
TMT 50xxxC
DIN-Rail Mounting Kit
Rev. 06/10
Adapter for mounting on DIN-rails as per EN 50022-35 (snap-on mounting)
Specifications can be changed any time without notice.
Kit contains interface plate, DIN-rail clip and necessary screws.
