http://www.tracopower.com Page 7 of 8
10.0
89.0
(3.50)
79.0
(3.11)
5.0
(0.20)
(0.39)
22.0
(0.87)
64.0
(2.52)
30.0
(1.18)
32.0
(1.26)
4.7 min.
(0.19)
Bottom view
1 2
43
17.0
(0.69)
3.0
(1.12)
3.0
(1.12)
AC/DC Power Modules
TMT Series 10 to 50 Watt
Outline Dimensions
Weight: 295 g (10.4 oz)
Pin diameter: 1.0 (0.04)
Pin Single
1
AC in
2
AC in
3
–V out
4
+V out
Connection
TMT 50 models with solder pins
TMT 50C models with screw terminal block
7.5
110.0
(4.33)
100.0
(3.93)
5.0
(0.20)
(0.30)
64.0
(2.52)
4x ø 3.5
(0.14)
33.5
(1.32)
3 4
2 1
(Top view)
49.0
(1.93)
Weight: 245 g (8.6 oz)
Dimensions in [mm], ( ) = Inches
Case tolerances: ±1.0 (±0.04)
Pin pich tolerance: ±0.5 (±0.02)
Mounting hole tolerance: ±0.5 (±0.02)
