Motherboard Manual
20
Manual Overclock System (M.O.S.)
MOS is designed for experienced overclock users.
It allows users to customize personal overclock settings.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset O.N. E
vxx. xx (C)C opyright 1985-200x, Americ an Megatren ds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Sav e and Exit
Exit
Ente r
F1
F10
ESC
Over-Clocking Navigator Setting
=========== Automate OverClock System ===========
============ Manual OverClock System ============
WARNING:Please Clear CMOS if system no display
afte r overclock ing
Over-Clocking Navigator [Normal]
Aut o OverCloc k System [ V6-Tech Engine]
Current CPU Frequency :
Current Memory Frequency :
Ove r Clock Retr y Count [ 1]
Intel(R) SpeedStep(tm) tech [Enabled]
CPU Ratio Setting [ x21.0]
CPU Frequency Setting [133]
DRA M Frequenc y [Auto ]
> D RAM Timi ng Confi guration
> Clock Gen Configuration
> Voltage Control
> Intel PPM Configuration
Exit
Option s
Normal
Automate OverClock
Man ual OverCl ock
Options
Norm al
Auto mate Ove rClock
Manual OverClock
↓
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset O.N. E
vxx. xx (C)C opyright 1985-200x, Americ an Megatren ds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Sav e and Exit
Exit
Ente r
F1
F10
ESC
Over-Clocking Navigator Setting
=========== Automate OverClock System ===========
============ Manual OverClock System ============
WARNING:Please Clear CMOS if system no display
afte r overclock ing
Over-Clocking Navigator [Manual OverClock]
Ove r Clock Retr y Count [ 1]
Intel(R) SpeedStep(tm) tech [Enabled]
CPU Frequency Setting [133]
DRA M Frequenc y [Auto ]
> D RAM Timi ng Confi guration
> Clock Gen Configuration
> Voltage Control
> Intel PPM Configuration
Aut o OverCloc k System [ V6-Tech Engine]
Current CPU Frequency :
Current Memory Frequency :
CPU Ratio Setting [ x21.0]
Exit
Option s
Normal
Automate OverClock
Man ual OverCl ock
Over Clock Retry Count
This item allows you to set the overclock fail retry times.
Intel(R) SpeedStep(tm) Tech
This item allows you to enable SpeedStep technology for better power
saving. SpeedStep is a technology built into some Intel processors that
allows the clock speed of the processor to be dynamically changed by
software.
CPU Ratio Setting
This item allows you to set the CPU ratio frequency. This item is adjustable
only when SpeedStep Tech is set to Disabled
CPU Fre que ncy Se tting
This item allows you to select the CPU Frequency.
