T5 XE/T5XE CFX-SLI
55
СПЕЦ
Разъём НГМД x1
Каждый разъём поддерживает 2 накопителя
на гибких магнитных дисках
Разъём IDE x1
Каждый разъём поддерживает 2 встроенных
интерфейса накопителей
Разъём SATA x6
Каждый разъём поддерживает 1 устройство
SATA
Разъём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Поддержка звуковых функций на лицевой
панели
Разъём ввода для CD x1 Поддержка функции ввода для CD
Разъём вывода для S/PDIF x1
Поддержка вывода цифровой звуковой
функц ии
Контактирующее приспособление
вентил ятора центрального процессора x1
Источник питания для вентилятор а
центрального процессора (с фун кц ией
интеллектуального вентилятора)
Контактирующее приспособление
вентил ятора системы x2
Источник питания для вентилятор а системы
Открытое контактир ующее
приспособление CMOS x1
USB-разъём x2
Каждый разъём поддерживает 2 USB-порта на
лицевой панели
Последовательный порт x1
Разъем питания (24 вывод) x1
Встроенны
й разъём
Разъем питания (4 вывод) x1
Задняя
панель
средств
ввода-выв
ода
Клавиатура PS/2 x1
Мышь PS/2 x1
Порт LAN x1
USB-порт x6
Гнездо для подключения
наушников x6
Размер
панели
220 мм (Ш) X 305 мм (В)
Поддержка
OS
Windows XP / Vista 32 / Vista 64 / 7
Biostar сохраняет за собой право добавлять
или удал ять средства обеспечения для OS с
или без предварительного уведомления.
