T5 XE/T5XE CFX-SLI
59
仕様
フロッピーコネクタ x1
各コネクタは2つのフロッピードライブをサポートし
ます
IDE コネクタ x1 各コネクタは2つのIDE デバイスをサポートします
SATAコネクタ x6 各コネクタは1つのSATAデバイスをサポートします
フロントパネルコネクタ x1 フロントパネル機能をサポートします
フロントオーディオコネクタ x1 フロントパネルオーディオ機能をサポートします
CDインコネクタ x1 CDオーディオイン機能をサポートします
S/PDIFアウトコネクタ x1 デジタルオーディオアウト機能をサポートします
CPUファンヘッダ x1 CPUファン電源装置(スマートファン機能を搭載)
システムファンヘッダ x2 システムファン電源装置
CMOSクリアヘッダ x1
USBコネクタ x2
各コネクタは2つのフロントパネルUSBポートをサポ
ートします
シリアルポート x1
電源コネクタ(24ピン) x1
オンボードコ
ネクタ
電源コネクタ(4ピン) x1
背面パネル
I/O
PS/2キーボード x1
PS/2マウス x1
LANポート x1
USBポート x6
オーディオジャック x6
ボードサイズ
220 mm (幅) X 305 mm (高さ)
OSサポート
Windows XP / Vista 32 / Vista 64 / 7
Biostarは事前のサポートなしにOSサポートを追加ま
たは削除する権利を留保します。
2009/09/22
