J1800TH
29
Italian
Specificazioni
Supporto
processore
Intel® Celeron® J1800 processor
Memoria
Supporta DDR3L 1066/1333 Doppio Canale (1.35V/1.5V)
2x DDR3L SO-DIMM Slot di Memoria Supporta fino a 16 GB Memoria
Ogni DIMM supporta non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L moduli
* Si prega di consultare www.biostar.com.tw
per la lista di supporto del
memoria.
Memorizzazione
Connettore 2x SATA 3Gb/s
Supporta nativo IDE & AHCI modo
Catena
Realtek RTL 8111G
10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo
Codec Audio
ALC662
Canali Audio di Alta Definizione 5.1
USB
Slot 6x USB 2.0 (1 nei ingressi/ uscite posteriore e 5 da distributori interni)
Slot 1x USB 3.0 (1 nei ingressi/ uscite posteriore)
Slot di
espansione
Slot 1x mini PCIe
Ingressi/ Uscite
Posteriore
Presa 1x CC-Ingresso 19V
1x porta VGA
1x porta HDMI
1x porta USB 3.0
1x porta USB 2.0
1x porta LAN
2x prese Audio (Ingresso Microfono, Uscita Linea)
Ingressi/ Uscite
Interni
2x connettori SATA 3.0Gb/s
1x connettore elettrico SATA
1x connettore elettrico 2-Perni
1x collettore pannello frontale
1x collettore audio frontale
2x collettore USB 2.0 2x5 (ogni collettore supporta 2 porte USB 2.0)
1x collettore USB 2.0 1x5 (supporta 1 porta USB 2.0)
2x connettori 4-Perni ventola
1x connettore schermo pannello frontale (LVDS)
1x connettgore luminosità schermo pannello frontale
1x collettore interruttore monitor
1x altoparlante stereo interno
1x ponticello pulizia CMOS
2x ponticello LVDS
1x ponticello voltaggio schermo pannello frontale
1x microfono digitale Header
Fattore di Forma Fattore di Forma Mini-ITX, 170 mm x 170 mm
Supporto SO
Windows 7 / 8 / 8.1
Biostar si riserva il diritto di aggiungere o ritirare il supporto per qualsiasi SO
con o senza preavviso.
