Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support Intel® Celeron® J1800 processor
Memory
Supports Dual Channel DDR3L 1066/1333 (1.35V/1.5V)
2x DDR3L SO-DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage 2x SATA 3Gb/s Connector, Supports Native IDE, AHCI Mode
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec ALC662, 5.1 Channels, High Definition Audio
USB
6x USB 2.0 port (1 on rear I/Os and 5 via internal header)
1x USB 3.0 port (1 on rear I/Os )
Expansion Slots 1x mini PCIe Slot
Rear I/Os
1x DC-IN 19V Jack
1x VGA Port
1x HDMI Port
1x USB 3.0 Port
1x USB 2.0 Port
1x LAN port
2x Audio Jack (Mic-In, Line-Out)
Internal I/Os
2x SATA 3.0Gb/s Connector
1x SATA Power Connector
1x 2-Pin Power Connector
1x Front Panel Header
1x Front Audio Header
2x USB 2.0 2x5 Header (each header supports 2 USB 2.0 ports)
1x USB 2.0 1x5 Header
2x 4-Pin Fan Connector
1x Front Panel Display Connector (LVDS)
1x Front Panel Display Brightness Connector
1x Monitor Switch Header
1x Internal Stereo Speaker
1x Clear CMOS Jumper
1x LVDS Voltage Jumper
2x LVDS Jumper
1x Front Panel Display Voltage Jumper
1x Digital Microphone Header
Form Factor Thin Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without
notice.
