Biostar J1800TH Версия 6.x [32/36] Japanese
![Biostar J1800TH Версия 6.x [32/36] Japanese](/views2/1710710/page32/bg20.png)
Motherboard Manual
30
Japanese
仕様
CPU サポート Intel® Celeron® J1800 processor
メモリ
デュアルチャンネル DDR3L 1066/1333 をサポート(1.35V/1.5V)
2x DDR3L SO-DIMM メモリ スロット、 最大 16GB メモリまでサポート
各 DIMM は、 非-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3L モジュールをサポート
しています
*サポートされているメモリのリストについては、www.biostar.com.tw
を参照
してください。
保存スペース
2x SATA 3Gb/s コネクタ
ネイティブ IDE & AHCI モード のサポート
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb/s オートネゴーシエーション、半/全 二重通信
オーディオ コー
デック
ALC662
5.1 チャンネル, ハイ デフィニション オーディオ
USB
6x USB 2.0 ポート (後部 I/O に1つ 及び 内蔵ヘッダー経由に5つ)
1x USB 3.0 ポート (後部 I/O に1つ)
拡張スロット 1x mini PCIe スロット
後部 I/O
1x DC-IN 19V ジャック
1x VGA ポート
1x HDMI ポート
1x USB 3.0 ポート
1x USB 2.0 ポート
1x LAN ポート
2x オーディオ ジャック (Mic-In、Line-Out)
内蔵 I/O
2x SATA 3.0Gb/s コネクタ
1x SATA電源コネクタ
1x 2-ピン電源コネクタ
1xフロントパネルコネクタ
1x フロントオーディオヘッダ
2x USB 2.0 2x5 ヘッダ (各ヘッダはUSB 2.0ポートの2つに対応)
1x USB 2.0 1x5 ヘッダ (USB 2.0 ポートの1つに対応)
2x 4-ピン・ファンコネクタ
1x フロントパネル・ディスプレイコネクタ (LVDS)
1x フロントパネル・ディスプレイ輝度コネクタ
1x モニタースイッチ・ヘッダ
1x 内蔵ステレオスピーカー
1x CMOS クリアジャンパ
2x LVDS ジャンパ
1x フロントパネル・ディスプレイ・電圧ジャンパ
1x デジタルマイクヘッダー
フォーム ファク
タ
Mini-ITXフォーム ファクタ、170 mm x 170 mm
サポート OS
Windows 7 / 8 / 8.1
Biostar には、通知なしでサポート OS を変更する権限があります。
