Planet VC-204 [10/28] Specifications

1.4 Specications

Product VC-201A VC-204

Hardware Specication

Ports

10/100Base-TX

1 RJ-45, Auto-negotiation

and Auto-MDI/MDI-X

4 RJ-45, Auto-negotiation

and Auto-MDI/MDI-X

VDSL 1 RJ-11, female Phone Jack

PHONE 1 RJ-11, Built-in splitters for POTS connection

DIP Switch 4 position DIP switch

Functionality

• CO / CPE mode select

• Selectable fast and interleaved mode

• Selectable target Band Plan

• Selectable target SNR mode

Encoding

• VDSL-DMT

- ITU-T G.993.1 VDSL

- ITU-T G.997.1

- ITU-T G.993.2 VDSL2 (Prole 17a)

LED Indicators

• One Power,

• 3 for RJ-11/VDSL2:

• 2 for per RJ-45

10/100Base-TX port

• One Power,

• 4 for RJ-11/VDSL2:

• 1 for per RJ-45

10/100Base-TX port

Cabling

Ethernet

• 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)

• 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)

VDSL

Twisted-pair telephone wires (AWG24 or better) up

to 1.6km
