Planet VC-204 [15/28] Led color function
![Planet VC-204 [15/28] Led color function](/views2/1071100/page15/bgf.png)
15
n VDSL
LED Color Function
ACT Green
Lit
Indicate that the VDSL link is
established.
Fast
Blink
Indicate that the VDSL link is at
training status(about 10 seconds).
Slow
Blink
Indicate that the VDSL link is at idle
status.
Off Indicate that the port is link down.
Sync Green
Lit
Indicate that the VDSL link is
established.
Fast
Blink
Indicate that the VDSL link is at
training status (about 10 seconds).
Slow
Blink
Indicate that the VDSL link is at idle
status.
CO Green Lit
Indicate the VDSL Bridge is running at
CO mode.
CPE Green Lit
Indicate the VDSL Bridge is running at
CPE mode.
n 10/100Base-TX Port
LED Color Function
LNK/
ACT
Green
Lit Indicate that the port is link up.
Blink
Indicate that the Converter is actively
sending or receiving data over that
port.
Off Indicate that the port is link down.
