to the telephone line system, on the other hand, need to install

a Slave (VC-201A / VC-204 CPE) converter on the individual

client side and connect to the Multi-port Master through the

telephone lines.

When deciding where to put the converter then you must

ensure:

It is accessible and cables can be connected easily.

Cabling is away from sources of electrical noise such as

radios, transmitters and power lines and uorescent lighting

xtures.

Water or moisture can not enter the Converter.

Air ow around the unit and through the vents in the side

of the case is not restricted (company recommend that you

provide a minimum of 25mm inch clearance)

To prolong the operational life of your units:

Do not place objects on top of any unit or stack

3.2 Connecting VC-201A / VC-204

3.2.1 Connecting Standalone PC

Refer to the following procedures to setup the VC-201A to a

standalone PC.

1. Set the VC-201A to be CO mode or CPE mode from the DIP

switch at the rear panel.

2. Power on the VC-201A by connecting its power source.

3. Power LED will illuminate.

4. Connect VDSL line from another VDSL device to VDSL port of

the VC-201A.

5. LNK LED will from blinking to illuminate.
