Planet VC-204 [18/28] Dc power jack

Target SNR (Signal Noise Ratio) Margin

u When xed SNR margin is selected, the system will main-

tain the SNR margin at 9 dB across all usable loop length.

Note

By default setting, the four DIP switch at “ON”

position and operate as “CPE”. For operate as

“CO”, please adjust the DIP 1 switch as “OFF”

position. Adjust other DIP switch setting to fill

different network application demand.

Please power off the Ethernet Over VDSL2 Converter, before

making any transmission mode adjustment.

2.2.2 DC power jack

VC-201A / VC-204 require 5V DC power input. It will conform

to the bundled AC adapter. Should you have the problem to

make the power connection, please contact your local sales

representative.

Note

1. The device is a power-required device, it

means, it will not work till it is powered. If

your networks should active all the time,

please consider using UPS (Uninterrupted

Power Supply) for your device. It will prevent

you from network data loss or network down-

time.

2. In some area, installing a surge suppression

device may also help to protect your Ethernet

Over VDSL2 Converter from being damaged by

unregulated surge or current to the Ethernet

Over VDSL2 Converter or the power adapter.
