DIP-1 DIP-2 DIP-3 DIP-4

Mode Channel Band Plan SNR

OFF CO Interleave Symm 9dB

ON (default) CPE Fast Asymm 6dB

CO / CPE

u CO (Central Ofce) – the Master device mode, usually

the CO device will be located at the data center of ISP or

enterprise to link to the backbone.

u CPE (Customer Premises Equipment) – the Slave device

mode, usually the CPE device will be located at branch

ofce, home or remote side as the long reach data receiver.

The CPE can be connect to the PC, IP Camera or Wireless

Access Point and etc network devices.

Note

When the Ethernet Over VDSL2 Converter operate

at CPE mode, the DIP switch 2,3,4 is no function.

Fast and Interleave mode

u Fast mode guarantees a minimum end to end latency less

than 1 ms.

u Interleaved mode provides impulse noises protection for

any impulse noise with a duration less than 250 us. Inter-

leaved mode has a maximum end to end latency of 10m

sec.

Band Plan

u User has the ability to select Band Plan. When Symmetric

is selected that provides better downstream performance,

when Asymmetric is selected that provides better upstream

performance. Refer to table above for details.
