For easily to know the TP / Fiber port link status of oppsite device, the Managed Media Converter Chassis System
provide OAM Setting that include TS-1000 OAM / IEEE 802.3ah OAM / Loop Back Test function. Also the
bandwidth control function allow to define available transmit / receive bandwidth on TP / Fiber port of FST-81x.
Item Description
Ingress Rate Limit Define receive rate for bandwidth control from TP and Fiber ports of FST-81x.
Egress Shaping
Define transmit rate for bandwidth control from TP and Fiber ports of FST-81x.
OAM Configuration Provide OAM Configuration on FST-81x.
#Notice:
Please refer to manual of Managed Media Converter Chassis (MC-1610MR/R48) for more detail about OAM Setting and
bandwidth control function.
15
