1.4 Specification
Model FST-811 FST-812 FST-815A FST-812S15 FST-812S35 FST-812S50
FST-816A
20
FST-816B
20
Hardware Specification
Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX
Ports 1 10/100Base-TX port , 1 100Base-FX port
Fiber connector ST SC SFP SC SC SC SC, WDM SC, WDM
Wavelength Deploy-
ment
1310nm (Transmit and Receive) 1310 (TX)
1550 (RX)
1550 (TX)
1310 (RX)
Cable
10Base-T: 2-pair Cat. 3,4,5 UTP cable, up to 100 meters
100Base-TX: 2-pair Cat. 5 UTP cable, up to 100 meters
100Base-FX: 50/125μm or 62.5/125μm multi-mode fiber cable, up to 2km. 9/125μm single-mode cable, provide long
distance for 2/15/20/35/40/50/60km
Maximum Cable dis-
tance
MM,2km MM,2km SM, 60km
(
MFB-F60
)
SM, 15km
SM,35km SM, 50km SM, 20km
Single wire
SM, 20km
Single wire
LED indicator
System: PWR
TP: LNK/ACT, 100
FX: LNK/ACT
DIP switch Flow control (Disable / Enable) , LFP function (Disable / Enable)
Speed
Ethernet: 10/20Mbps for half / full-duplex
Fast Ethernet: 100/200Mbps for half / full-duplex
Power input DC 5V 2A
Power consumption 2.8 Watts / 9 BTU (maximum)
Operate environment 0~50 Degree C, 5%~90%RH
Storage environment -10~70 Degree C, 5%~90%RH
Dimension (W x D xH) 81 x 94 x 26 mm
Weight 0.22kg
Emission FCC Class B, CE mark
6
