Motherboard Manual
30
APPENDIX: SPEC IN OTHER LANGUAGES
G
ERMAN
Spezif ikationen
CPU
Sockel AM3
AMD Phenom II/ Athlon II Prozessoren
(Maximales Watt: 95W)
Die AMD 64-Architektur unterstützt eine 32-Bit- und
64-Bit-Datenverarbeitung
Unterstützt Hyper Transport 2.0
FSB
Unterstützt HyperTransport 2.0 mit einer
Bandbreite von bis zu 2.0 GT/s
Chipsatz GeForce 6150 SE/nForce 430
Super E/A
ITE 8718F
Bietet die häufig verwend eten alten Sup er
E/A-Funktionen.
Low Pin Count-Schnittstelle
Umgebungskontrolle,
Hardware-Überwachung
Lüfterdrehzahl-Controller
"Smart Guardian"-Funktion von ITE
Arbeitsspeich
er
DDR3 DIMM-Steckplätze x 2
Max. 8GB Arbeitsspeicher
Jeder DIMM unterstützt 512MB/
1GB/2GB/4GB DDR3.
Dual-Kanal DDR3 Speichermodul
Unterstützt DDR3 800 / 1066 / 1333
registrierte DIMMs. ECC DIMMs werden nicht
unterstützt.
Grafik GeForce 6150 SE/nForce 430
Max. 512MB gemeinsam benutzter Videospeicher
(under OS)
IDE Integ r iert er IDE-Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Master-Modus
Unterstützt PIO-Modus 0~4,
SATA II Integrierter Serial ATA-Controller
Datentransferrate bis zu 3Gb/s
Konform mit der SATA-Spezifikation Version 2.0.
LAN Realtek RTL 8201CL
10 / 100 Mb/s Auto-Negotiation
Halb-/ Vollduplex-Funktion
Audio-Codec ALC662 / VT1708B
5.1-Kanal-Audioausgabe
Unterstützt High-Definition Audio
PCI-Steckplatz x2
Steckp lätze
PCI Express x16 Steckplatz x1
Diskettenlaufwerkanschluss x1 Jeder Anschluss unterstützt 2 Diskettenlaufwerke
Druckeranschluss Anschluss x1 Jeder Anschluss unterstützt 1 Druckeranschluss
Onboard-Ans
chluss
IDE-Anschluss x1 Jeder Anschluss unterstützt 2 IDE-Laufwerke
