MCP6P3
39
ESPECIFICAÇÕES
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áudio frontal x1 Suporta a função de áudio no painel frontal
Conector de saída S/PDIF x1 Suporta a saída de áud io digital
Conector da ventoinha da CPU x1
Aliment ação da ventoinha da CPU (com a função S mart
Fan)
Conector da ventoinha do sistema x1 Alimentação da ventoinha do s istema
Conector para limpeza do CMOS x1
Conector USB x3 Cada conector suporta 2 portas USB no painel frontal
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Entradas/S
aídas no
painel
traseiro
Tec l ad o PS /2 x 1
Rato PS/2 x1
Porta VGA x1
Porta série x1
Porta LAN x1
Porta USB x4
Tomada de áudio x3
Tamanho
da placa
190 mm (L) X 244 mm (A)
Característi
cas
especiais
Suporta as funções RAID 0 / 1 / 0+1 / 5
Sistemas
operativos
suportados
Windows XP / Vista / 7
A BIOSTAR reserva-se o direito de adicionar ou
remover suporte para qualquer sistema operativo com
ou sem aviso prévio.
