Motherboard Manual
32
FRENCH
SPEC
UC
Socket AM3
Processeurs AMD Phenom II/ Athlon II
(Watt maximum : 95W )
L'architecture AMD 64 permet le calcul 32 et 64 bits
Prend en charge Hyper Transport 2.0
Bus frontal
Prend en charge Hyper Transport 2.0
jusqu'à une bande passante de 2.0 GT/s
Chipset GeForce 6150 SE/nForce 430
Super E/S
ITE 8718F
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à f aib le co mpte de b roches
Initiatives de contrôle environnementales,
Mon iteur d e mat ér iel
Contrôleur de vitesse de ventilateur
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR3
de 512Mo/1Go /2Go/4Go
Modu le d e mémo ire DDR3 à mod e à doub le vo ie
Prend en charge la DDR3 800 / 1066 / 1333
Les DIMM à registres et DIMM avec code correcteurs
d'erreurs ne sont pas prises en charge
Graphiques GeForce 6150 SE/nForce 430
Mémoire vidéo partagée maximale de 512 Mo (under
OS)
IDE Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100 / 133
Prend en charge le mode PIO 0~4,
SATA II
Contrôleur Serial ATA
int égr é :
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spécif icat ion SATA Vers ion 2.0
LAN Realtek RTL 8201CL
10 / 100 Mb/s négociation automatique
Half / Full duplex capability
Codec audio
ALC662 / VT1708B
Sortie audio à 5 .1 vo ies
Prise en charg e de l'aud io haute definition
Fente PCI x2
Fentes
Slot PCI Express x16 x1
Connecteur de disquette x1
Chaque connector prend en charg e 2 lecteurs de
disquettes
Connecteur de Port d'imprimante x1 Chaque connector prend en charge 1 Port d'imprimante
Connecteur
embarqué
Connecteur IDE x1
Chaque connecteur prend en charge 2 périphériques
IDE
