MCP6P3
35
SPECIFICA
Connettore pannello frontale x1 Supporta i serviz i del pannello frontale
Connettore audio frontale x1 Supporta la funzione audio pannello frontale
Connettore output SPDIF x1 Supporta la funzione d’output audio digitale
Collettore ventolina C PU x1
Alimentazione ventolina CPU (con funzione Smart
Fan)
Collettore ventolina sistema x1 Alimentazione ventolina di sistema
Collettore cancellaz ione CMOS x1
Connettore USB x3
Ciascun connettore supporta 2 porte USB
pannello frontale
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(4 pin)
I/O
pannello
posteriore
Tas tier a PS /2 x 1
Mouse PS/2 x1
Porta VGA x1
Porta seriale x1
Porta LAN x1
Porta USB x4
Connettore audio x3
Dimension
i scheda
190 mm (larghezza) x 244 mm
(altezza)
Caratterist
iche
speciali
Supporto RAID 0 / 1 / 0+1 / 5
Sistemi
operativi
supportati
Windows XP / Vista / 7
BIOSTAR si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
