MCP6P3
41
SPEC
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze wyjścia S/PDIF x1 Obsługa funkcji cyfrowego wyjścia audio
Złącze głó wkowe wentylatora
procesora x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącze głó wkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Złącze główkowe kasowania
CMOS x1
Złącze USB x3
Każde złącze obs ługuje 2 porty USB na panelu
przednim
Złącze zasilania (24 pinowe) x1
Złącze zas ilania (4 pino we) x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port szeregowy x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Wymiary
płyty
190 mm (S) X 244 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 0+1 / 5
Obsluga
systemu
operacyjne
go
Windows XP / Vista / 7
BIOSTAR zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego bez powiado mienia.
