Motherboard Manual
40
POLISH
SPEC
Procesor
Socket AM3
AMD Phenom II/ Athlon II Procesory
(Maksymalny Watt: 95W)
Architektura AMD 64 umożliwia przetwarzanie 32 i 64
bitowe
Obsługa Hyper Transport 2.0
FSB
Obsługa HyperTransport 2.0 o szerokości
pasma do 2.0 GT/s
Chipset GeForce 6150 SE/nForce 430
Pamięć
główna
Gniazda DDR3 DIMM x 2
Maks. wielkość pamięci 8GB
Każde gniazdo DIMM obsługuje moduły
512MB/1GB/2GB/4GB DDR3
Moduł pamięci DDR3 z trybem podwójnego kanału
Obsługa DDR3 800 / 1066 / 1333
Brak obsługi Registered DIMM oraz ECC DIMM
Super I/O
ITE 8718F
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H/W
Kontroler prędkości wentylatora
Funkcj a ITE "Smart Guard ian"
Grafika GeForce 6150 SE/nForce 430
Maks. wielkość współdz ielon ej pamięci video wynosi
512MB (under OS)
IDE Zintegrowany kontroler IDE
Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master
obsługa PIO tryb 0~4,
SATA II Zintegrowany kontroler Serial ATA
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersj i 2.0.
LAN Realtek RTL 8201CL
10 / 100 Mb/s z automatyczną negocjacją szybkości
Działanie w trybie połowicznego / pełnego dupleksu
Kodek
dźwiękowy
ALC662 / VT1708B
5.1 kanałowe wyjście audio
Obsługa High-Def inition Aud io
Gniazdo PCI x2
Gniazda
Gniazdo PCI Express x16 x1
Złącze napędu dyskietek x1 Każde złącze obs ługuje 2 napędy dyskietek
Złącze Port drukarki x1 Każde złącze obs ługuje 1 Port drukarki
Złącze IDE x1 Każde złącze obs ługuje 2 urządzenia IDE
Złącze SATA x4 Każde złącze obs ługuje 1 urządzenie SATA
Złącza
wbudowan e
Złącze panela przedniego x1 Obsługa elementów panela przedniego
